Sinclair AMC-09C User Manual

－18－
INSTALLATION GUIDE FOR CASTOR, DRAINAGE PIPE AND AIR EXHAUST ACCESSORY
CAUTION
1.In order to correctly installing the air exhaust duct please
contact your local dealer for the service.
2.When mounting, try to keep the square end of the exhaust
duct horizonal.
3.Don't add or connect other pipes to it, otherwise it will cause
mechanical malfunction.
Window kit
Rear Clip B
Window
Plastic Pipe End
Hole( 132mm)
Window Or wall
Fig 5
Fig 6
Ø
