Installation and Maintenance
Service Manual
Screws
Motor
Cross ow
Step Procedure
8.Remove motor and cross ow blade
a
b
Remove 3 screws xing motor clamp and then remove
the motor clamp.
Remove the at the connection place of cross ow blade
and motor; lift the motor and cross ow blade upwards
to remove them.
9.Remove vertical louver
Loosen the connection clasps between vertical louver
and bottom case to remove vertical louver.
Motor clasp
Clasps
Vertical louver
Clasps
