Sinclair ZX Spectrum Service Manual
Spectrum For Everyone https://spectrumforeveryone.com/
34
5.3 CASE ASSEMBLY COMPONENTS
Description
Manufacturer
Base Assembly
Final PCB Assembly Table 5.4
Heatsink
Retractable legs 2 off
Leg Springs 2 off
Bottom Case Moulding
Fixings
¼ in self tap screw 3 off
PCB
Fibre washer 3 off
5/16 in self tap screw 2 off
Heatsink
M3 x 10mm pan hd screw 1 off
Voltage Regulator
M3 plain washer 1 off
M3 crinkle washer 1 off
M3 hex nut 1 off
Keyboard Assembly
Keyboard reaction plate
Spectrum + Membrane
Bubble Mat
Upper Case Moulding
Key Set
Tail Clamps 2 off
Fixings
Double sided adhesive tape
12mm wide (Tesafix 959)
¼ inch self tap screw 4 off
Tail clamps
5/16 inch self tap screw 10 off
Reaction plate
General Assembly Fixings
5/16 in self tap screw 6 off
Base/keyboard
½ in self tap screw 2 off
