EA180 Series Servo Drive Users Manual
11
1.2.4 Block diagram of EA180 servo drive
Operation
panel
CN4
CN2/
CN3
CN1
CN5
M
Enco
der
Servo motor
Rectifying circuit
+
P
External braking resistor
Servo drive
Retrogradation
processing circuit
IGBT module
U
V
W
IGBT drive
Protection
circuit
L1
L2
L3
Control power
supply
+15V
+5V
+3.3V
+24V
L1C
L2C
A/D
Position
control
Speed
control
Current
control
To DSP
PWM
DSP
CPLD
From
protection
circuit
Data Bus
External speed
External torque
Position pulse
A, B, Z outputs
Digital input
Digital output
Analog output
D/A
Current signal
processing
A/
D
Encoder
signal
processing
D C
Cooling
fan
Power Supply
Single/three-phase
AC220V
Three-phase AC380V
RS232
RS485
Internal
braking
resistor
CHAR
GE
Electrolytic capacitor
L3 not used
for single
phase
