Singer 14T957DC - Upper Looper Position to Left Needle; Check Upper Looper Position; Setting Upper Looper Position

12
B
1047306-26
9. Upper looper position to the left needle
Check:
1. Turn the handwheel in the normal direction until the upper looper is at its most left position.
2. The distance between upper looper point to the left needle "A" must now be 4.6 mm (B).
Setting:
1. Turn the handwheel in the normal direction until the upper looper is at its most left position.
2. Slightly loosen fastening screw (C) .
3. Move the upper looper arm until the distance between the upper looper point and the left
needle "A" is 4.6 mm (B).
4. Tighten fastening screw (C).
5. Re-check as described under “Check".
