Singer 14T957DC - Chain Stitch Loopers Thread Take Up; Check Chain Stitch Loopers Thread Take Up; Setting Chain Stitch Loopers Thread Take Up

27
1.5 mm
1047306-26
24. Set the Chain stitch loopers thread take up.
Check
The Left chain stitch loopers thread take up should be 1.5 mm from the right chain stitch
looper
Setting
1. Loosen up the set screw (B)
2. Move the thread take up so it it is 1.5 mm clearance.
3. Tighten the set screw (B).
