Singer 14T957DC - Lower Looper Lower Thread Guide; Check Lower Looper Lower Thread Guide; Setting Lower Looper Lower Thread Guide

24
A
B
1047306-26
21. Set the Lower Looper lower thread guide
Check
The lower looper brackets left side should be fl ush with the lower looper right side (A).
Setting
1. Open up the set screw (B)
2. Move the thread guide until the correct measurement is achieved.
3. Tighten the set screw (B)
