Singer 7285Q - Disassembling of Covers; Face Cover Side; Bottom Cover Side

Page 3/38
Original issue
May, 2014
Service Manual
7285Q
Model
1. Disassembling of covers
(1) Face cover side
(2) Bottom cover side
A
B
Remove screw A.
Remove screw B.
Loosen five screws.
