Page 32/38
Original issue
May, 2014
Service Manual
7285Q
Model
17. Electronic component area
AC Power Board
87553
5P Connector cord
Connect with CPU
Transformer
Primary
LED lamp
harness
Transformer
Secondary
Main motor DC 230v
