Singer 7285Q - Needle Stop at Highest Position

Page 31/38
Original issue
May, 2014
Service Manual
7285Q
Model
16. Needle stop at highest position
Needle always stops at its highest position. This is controlled by sensor cam and sensor
located on main shaft.
Adjustment:
1. Raise needle to its highest position.
2. Loosen two screws (B1& B2) on collar (A) fixing sensor cam.
3. Turn collar (C) in either direction until needle stops at its highest position.
4. Check to see if take-up lever stops at the position for threading easy after adjustment.
5. If there is no problem, tighten two screws (B1 & B2) securely.
(Front View)
Sensor cam
B1 & B2
A
