sinmag LBC LMO Max-E - ILLUSTRATED PARTS BREAKDOWN - Part 10; Detailed Parts List (100-207)

© Copyright 2017-2022 LBC Bakery Equipment, Inc. 35 Rev 6/2022
100
Frame, Light Cover
3
151-583-1
101
Glass, Light Cover
3
151-583-2
102
Gasket, Light Cover
3
151-583-4
103
Light Assembly
3
31602-31
104
Xenon Lamp
3
31602-28
110
Motor, Rack Rotation
1
30200-56-1
111
Rotator Cam
1
151-523
112
Bushing
1
50803-002
113
Drive Gear
1
73000-05c
114
Bottom Assembly - Rotator
1
151-739
115
Snap Ring
1
20601-04
116
Lifting Blade - Rotator
1
151-579
117
Bushing, Flange
1
70200-11
118
Driven Gear
1
73000-06a
119
Bushing, Gear
1
70200-13
120
Friction Washer
1
70200-14
121
Top Channel - Rotator
1
150-151a
122
Roller Switch
1
30301-15
123
Thrust Bearing
1
70200-12
124
Rotation Capacitor
1
40704-12
135
Motor, Blower
1
30200-66
136
Clamp, Blower Seal
1
151-271
137
Seal, Blower
1
151-270
138
Blower Wheel
1
151-801
150
Contactor
1 or 2
30700-17
151
Transformer
2
31400-32
152
Terminal Block
1
30500-07
153
Ground Lug
1
31200-08
154
Terminal Block
1
30500-01
155
Breaker (50A)
2
31800-12
Max-E only
170
Element (208V)
3
151-802-208
208V Max-E only
Element (240V)
3
151-802-240
240-480V Max-E
180
Gas Control Module
1
80300-18
Max-G only
195
Heat Exchanger
1
151-703-3-G
Max-G only
200
Burner Assembly
1
151-763-1
Max-G only
201
Flame Sensor
1
41100-36-7
Max-G Only
202
Ignitor
1
80302-12
Max-G only
203
In-shot Burner
8
80002-15
Max-G only
204
Orifice
8
80400-49
Natural Gas
205
Draft Inducer
1
30200-86
Max-G only
206
Flexible Gas Connector
1
70302-09
Max-G only
207
Gas Valve
1
80505-15
Max-G only
