Sinoboom 4047E - APPENDIX 1: SYMBOLS AND DESCRIPTION; Symbols Chart

GTJZ0612E&0812E&1012E&1212E Operation Manual A-1 © Jun 2020
APPENDIX 1: SYMBOLS AND
DESCRIPTION
SYMBOLS CHART
Read maintenance
manual
Anchor point allows
only 1 person to tie
Close the chassis door
box
Press the change
valve
Repeatedly move man-
ual brake release valve
Wind speed Chemical burns
hazards
Wedge the wheel Release the brake Wind
Noise level Burns hazards Keep a safe distance
from high
temperatures
Pull out-open
Press-close
Step-open
Release-close
Hydraulic oil level - low
position
Hydraulic oil level -
high position
Temperature Change the tires of the
same specification
Only trained mainte-
nance personnel can
access the bulkhead
Read operation
manual
Add lubricant Crushing hazard-
Please wear work
shoes
Danger of hot, high
pressure fluids
Collision hazards-Re-
lease brake on ramp
Electrocution hazards
on platform
Electrocution hazards
on the ground and
platform
Keep a safe distance
from power lines
Tip-over hazards-Avoid
uneven ground
Tip-over hazards-Avoid
uneven ground
