OPTIONS
platform in the same way.
4. Fasten the strap to tightly secure it to the bracket.
Removal instructions
Disassemble the pipe cradles in the reverse order of the
installation instructions.
Instructions for Use
Tipping Hazard
• The pipe cradle and the load upon
will affect the load capacity of the
platform, thus must be factored
into the total platform capacity.
• In case of excessive combined
weight of the pipe cradle and the
load upon, the maximum number
of people on the platform should
be reduced.
Table 11-6
Pipe cradle capacity 100kg (220lbs)
Pipe cradle assembly
weight
6kg (13lbs)
After the pipe cradle is installed, follow the below in-
structions for use:
1. Ensure that the pipe cradles are installed correctly
and secured to the platform.
2. Place the load upon the pipe cradle, and ensure that
the load length remains parallel with the pipe cradle
length.
3. Ensure the load is centered on the same vertical
plane with the center of the pipe cradle.
4. Use the straps to secure the load to the both pipe
cradles.
5. Gently push and pull on the load to ensure that the
load is securely secured.
6. When the machine is operating, ensure that the load
is always secured in place.
11.3 PANEL CRADLE
Self-propelled boom-supported elevating work platforms
are designed to transport people, tools and materials to
aerial workplaces. When it is needed to transport the
panel materials to an aerial position, the panel cradle
serves as a supporting unit to hold and secure the panel
materials for safe transport.
Unsafe Operation Hazard
• Except for designated models
and corresponding markets, it is
forbidden to install the panel cra-
dle on products with other models
or in other markets than specified.
• Before using the panel cradle, the
safety rules and all operating in-
structions should be read, under-
stood and observed. This manual
should always be kept as an inte-
gral part with the panel cradle.
