3 TECHNICAL CHARACTERISTICS
3.1 MACHINE SPECIFICATIONS
Table 3-1 GTZZ14EJ specifications
ITEM
Metric Imperial
Product Category
Power type Battery
Outrigger type Fixed outrigger
DIMENSION
Maximum platform height
14m 45ft 11in
Maximum working height
16m 52ft 6in
Maximum horizontal reach 7.6m 24ft 11in
Maximum horizontal working
envelope
8.2m 26ft 11in
Maximum up and over height
7.8m 25ft 7in
Overall length (stowed)
6m 19ft 8in
Overall length (transport)
6m 19ft 8in
Overall width (stowed)
1.73m 5ft 8in
Overall width (transport)
1.73m 5ft 8in
Overall height (stowed)
2m 6ft 7in
Overall height (transport)
2m 6ft 7in
Wheelbase 1.9m 6ft 3in
Ground clearance 0.22m 8.7in
Platform dimension (L×W×H)
Options
1.45×0.85×1.1m
1.83×0.85×1.1m
Options
57×33.5×43in
72×33.5×43in
PERFORMANCE
Rated platform capacity 230kg (unrestricted) 507lb (unrestricted)
Maximum number of occupants 2 persons (unrestricted)
Maximum travel speed (stowed)
5.2km/h
3.2mph
Maximum travel speed (raised)
0.8km/h
0.5mph
Turntable rotation (angle/continuity)
355°/non-continuous
Platform rotation angle
160°
Gradeability （2WD）
30%/17°
Maximum allowable inclination 5°
