Table 3-2 GTZZ16EJ specifications
ITEM
Metric Imperial
Product Category
Power type Battery
Outrigger type Fixed outrigger
DIMENSION
Maximum platform height
15.7m 51ft 6in
Maximum working height
17.7m 58ft 1in
Maximum horizontal reach 9.3m 30ft 6in
Maximum horizontal working
envelope
9.9m 32ft 6in
Maximum up and over height
7.8m 25ft 7in
Overall length (stowed)
6.8m 22ft 4in
Overall length (transport)
6.8m 22ft 4in
Overall width (stowed)
1.9m 6ft 3in
Overall width (transport)
1.9m 6ft 3in
Overall height (stowed)
2m 6ft 7in
Overall height (transport)
2m 6ft 7in
Wheelbase 1.9m 6ft 3in
Ground clearance 0.22m 8.7in
Platform dimension (L×W×H)
Options
1.45×0.85×1.1m
1.83×0.85×1.1m
Options
57×33.5×43in
72×33.5×43in
PERFORMANCE
Rated platform capacity 230kg (unrestricted) 507lb (unrestricted)
Maximum number of occupants 2 persons (unrestricted)
Maximum travel speed (stowed)
5.2km/h
3.2mph
Maximum travel speed (raised)
0.8km/h
0.5mph
Turntable rotation (angle/continuity)
355°/non-continuous
Platform rotation angle
160°
Gradeability （2WD）
30%/17°
Max allowable tilt angle
5°
Turning radius (inside/outside)
0.7m/3.31m
2ft 4in/10ft 10in
Turntable tail-swing
50mm
2.0in
Tire size (spec/type)
Options
250–15 (solid)
240/55D17.5 (foam-filled)
27×10.5-15 (rough-terrain, foam-filled)
27×10-15 (rough-terrain, solid)
To Next Page
