Sinoboom GTJZ0608 - Page 5

Hydraulic oil tank L 14 14
Hydraulic system
L 20 (Oil tank) 21 (Oil tank)
Pressure of hydraulic system bar 240 240
System voltage (DC) V 24 24
Maximum noise for normal
working
dB 72 72
Traveling speed
Off-running status km/h 0～3.2 0～3.2
Lifting status km/h 0～0.8 0～0.8
Gradeability % 25 25
Lifting/lowering time s 35/33 (No load) 35/37 (No load)
Maximum allowable wind speed
Outdoor type
m/s 0 (indoor)/ 12.5 (Gale
Level 6)
0 (indoor)/ 12.5 (Gale Level
6)
Maximum allowed inclined angle Front and rear 3°/Left
and right 1.5°
Front and rear 3°/Left and
right 1.5°
Parameter Items Unit GTJZ1012 GTJZ1212
Outline dimension
Length
m 2.39 2.39
Width
m 1.15 1.15
Height (Folded railings)
m 1.86 1.98
Height (Unfolded railings)
m 2.48 2.60
Ground clearance mm 100 100
Ground clearance (Pit protection
device stretches)
mm 22 22
Total weight (Indoor use only) kg 2380 2615
Total weight (For indoor / outdoor
use)
kg 2570 2900
Design dimension
Maximum platform height
m 10 11.9
Maximum working height
m 12 13.9
Maximum horizontal
extension
m 0.9 0.9
Maximum bearing capacity kg 320 320
Maximum bearing capacity of
extended platform
kg 120 120
Allowable quantity of people
working on the platform
Person 2 (indoor)/1 (outdoor) 2 (indoor)/1 (outdoor)
Wheel base m 1.85 1.85
Wheel span m 1.15 1.15
Turning radius
Internal wheel m 0 0
External wheel m 2.35 2.35
Maximum allowable yawing force N 400 (indoor)/200
(outdoor)/
400 (indoor)/200 (outdoor)
3
GTJZ0608 & GTJZ0808 & GTJZ1012 & GTJZ1212 & GTJZ0612 & GTJZ0812 Operation Manual
