GTZZ25J Operation Manual 1-1 © Nov. 2022
1 PERFORMANCE PARAMETERS
Table 1-1 GTZZ25J specifications
Items
AB25J (Metric) AB810J (Imperial)
DIMENSION PARAMETERS
Max platform height
24.6 m 80ft 9in
Max working height
26.6 m 87ft 3in
Max horizontal reach 16.1 m 52ft 10in
Max working envelope
16.7 m 54ft 9.5in
Max cross-over height
9.4 m 30ft 10in
Overall length (stowed)
11.51 m 37ft 9in
Overall width (stowed)
2.49 m 8ft 2in
Overall height (stowed)
3.2 m 10ft 6in
Wheelbase 3.05 m 10ft
Ground clearance 0.39 m 15.4in
Tire size (spec/type)
Options
385/65-22.5 (foam-filled)
385/65-24/10.00 (solid)
12.00-20/8.5
15-625 (foam-filled)
385/45-28 (foam-filled, non-marking)
385/65-24/10 (solid, non-marking)
Platform dimension (L×W×H)
Options
1.45×0.85×1.1 m
1.83×0.85×1.1 m
2.44×0.91×1.1 m
Options
57×33.5×43.3 in
72×33.5×43.3 in
96×36×43.3 in
PERFORMANCE PARAMETERS
Max platform capacity
230kg (unrestricted/2 persons &
tools)
507 lb (unrestricted/2 persons &
tools)
Turntable rotation/continuity
360 °/continuous
Platform rotation 160°
Max drive speed (stowed)
4.4 km/h
2.7 mph
Max drive speed (raised)
1.1 km/h
0.68 mph
Drive mode (drive×steer)
4WD×2WS/2WD×2WS
Gradeability 45 % (4WD)/ 30 % (2WD)
Turntable tailswing
1 m
3 ft 3in
Max allowable inclination 5°
Turning radius (inside)
3m 9ft 10in
