4. TECHNICAL SPECIFICATION
Measured objects: Solid particles (dust) in a gas flow
Particle size: 0.3 m or larger
Measurement range: 0.1 mg/m
3
to 1 kg/m
3
Process Conditions:
Temperature: Max. 300°C (standard) / Max. 700°C
(optional)
Pressure: Max. 200 kPa
Gas velocity: Min. 4 m/s
Humidity: 95 % RH or less (non-condensing)
Input surge voltage: Max. 100 V
Measurement principle: Inductive Electrification
Output damping time: 0 to 300 seconds
Output signals: Isolated 4-20 mA
Relay 5 A , 24 V AC or DC
Ambient conditions:
Temperature: -20 to + 45
o
C
Humidity: 95% RH (non-condensing)
Vibration: 5 m/s
2
or less
Materials:
Probe: SS 316L
Insulation of sensor: PEEK (300
o
C), Teflon (250
o
C)
Enclosure: Aluminium alloy
Power Supply: 115 VAC or 230 VAC or 24 VDC
Power consumption: 8 W AC models, 3 W 24 VDC model
Wiring connections: DIN PG11 port for power cables
DIN PG11 port for signal cable
Weight: 2.3 kg
Protection class: IP 65
Range setup options:
Normal measuring range: -automatic, based on average measured
dust flow
Extended measuring range: - (option) set at factory
Alarm threshold: Adjustable via internal keys or via serial port.
Zero point offset trim: Automatic
This instrument conforms to the following standards
