SILVERCUT
13
1. See instruction handbook of the tractor.
2. See price list and / or instruction handbook of the
implement.
3. To be measured.
Key (GB)
T
E
(kg) Unladen weight of tractor 1
T
F
(kg) Front axle load of unladen tractor 1
T
R
(kg) Rear axle load of unladen tractor 1
I
R
(kg) Combined weight of rear mounted implement / rear weight 2
I
F
(kg) Combined weight of front mounted implement / front weight 2
a (m) Distance from front axle centre to centre of lower link balls 1,3
b (m) Tractor wheelbase 1,3
c (m) Distance from rear axle centre to centre of lower link balls 1,3
d (m)
Distance between centre of the coupling balls and centre of gravity of rear
mounted machine/rear weight (d = 0.5m)
e (m)
Distance between centre of the coupling balls and centre of gravity of front
mounted machine/front weight (d = 0.4m)
