Specifications
INfinity 510 User’s Guide, P1.04
17
Specifications
Reader Specifications
Frequency 860-960 MHz
RF Power 10 mW – 2W conducted
Connections RS-232, Digital I/O, Ethernet LAN, and
WiFi 802.11 (optional)
Input Voltage 12 to 24 Vdc, 60W
Input Current 2.5A maximum at 24 Vdc
5.0A maximum at 12 Vdc
Environmental Specifications
Operating Temperature -4° F to 131° F (-20° C to 55° C)
Storage Temperature -40° F to 185° F (-40° C to 85° C)
Maximum Shock 1 foot (0.3 meter) drop to any corner
Relative Humidity 5% to 95% non-condensing
Case Material Aluminum
Case Dimensions 8.7 x 11.8 x 2.2 in (220 x 300 x 56 mm)
Weight 4 lbs (1.8 kg)
Battery Specifications (Optional)
Battery Lithium/Manganese Dioxide
Designation ANSI/NEDA 5012LC / IEC-CR1220
Voltage 3.0 volts
Average capacity 40 mAh to 2.0 volts
Caution - Risk of Explosion
Only replace battery with same type and designation. There is risk of explosion if
battery is replaced with incorrect type. Dispose of old battery according to
manufacturer’s instructions and local regulations.
