Specifications
18
INfinity 510 User’s Guide, P1.04
Power Supply Specifications
Input Voltage 100 – 240 Vac
Input Consumption 60W maximum
Input Frequency 50 – 60 Hz
Output Voltage 15 VDC
Output Current 4A maximum
RS-232 Specifications
Connector DB-9S
Baud rate 9600 - 115200 (Default = 57600)
Parity None
Data bits 8
Stop bits 1
Signals
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
Pin 9
CNVSS
TXD
RXD
DTR
GND
DSR
CTS
RTSA
+3.3 Vdc
Ethernet LAN Specifications
Connector RJ-45
Ethernet 10/100 BaseT
Indicators Yellow - Indicates link is operational
Green - Indicates network traffic detected.
Signals
Pin 1 – TXD+ (Transmit Data +)
Pin 2 – TXD- (Transmit Data -)
Pin 3 – RXD+ (Receive Data +)
Pin 4 – EPWR+ (Power from switch +)
Pin 5 – EPWR+ (Power from switch +)
Pin 6 – RXD- (Receive Data -)
Pin 7 – EPWR- (Power from switch -)
Pin 8 – EPWR- (Power from switch -)
