CONSULTATION SCREENS
1 GENERAL
2 PROGRAMS
3 SECTORS
4 FERTILIZERS
5 FILTERS ↓
6 COMMUNICATION
7 AGRÓNIC
GENERAL CONSULTATION
Sun 21/07/14 16:45:05
New anomalies: 02
No irrig. in process
IM1 CS
1
CON. P06
Irrigating
Sectors: 02 03
Irrigation: 0083,5 m3
Fert. 1: 00118 L
CON. S03
Active
Program: 06
Irrigation: 0083,5 m3
FILTER CONSULTATION
Cleaning stopped
Units between cleanings:
Time: 00063 ‘
Volume: 00583 m3
5
COMMUNIC. CONSULTATION
“check specific manual”
6
AGRÓNIC CONSULTATION
NS: 00001 V: 1.10 Relays
V. Out.: yes V. Panel: no
Vdc: 11,8 v
7
FERTILIZER CONSULTATION
F1: 00118 L M1: 000”
F2: 00073 L M2: 024” ope
F3: 00109 L
F4: 00043 L M4: 000”
Cleaning: 020”
4
PROGRAMS CONSULTATION
01. 02f 03f 04. 45.
06R 07. 08. 09a 50.
N. program: 00
PROGRAMS CONSULTATION
01. 02f 03f 04. 25.
06R 07. 08. 09a 30.
11. 12. 13. 14. 35.
36. 37. 38. 39. 40.
N. program: 00
PROGRAM CONSULTATION
01. 02 03 04. 05.
06R 07. 08. 09a 10.
11. 12. 13. 14. 15.
16. 17. 18. 19. 20.
N. program: 06
2
SECTOR CONSULTATION
21. 22. 23. 24. 25.
26. 27. 28. 29. 30.
N. sector: 03
SECTOR CONSULTATION
01. 02R 03R 04. 05.
06. 07. 08. 09. 10.
11. 12. 13. 14. 15.
16. 17. 18. 19. 20.
N. sector: 03
3
