PARAMETERS SCREENS
PARAMETERS
1 Fertilization
2 Filters
3 Generals
4 Programs
5 Sectors ↓
6 Communications
7 Various
8 Installer
FERTILIZATION PARAMETERS
N. of fertilizers: 4
Fertilizer general: yes
Mixer F1: no
Mixer F2: yes
Mixer F3: yes
Mixer F4: no
Pre-mixer: 015”
Mixing start: 030 “
Mixing stop: 120 “
Last cleaning: 030 “
SECTOR PARAMETERS
Sector: 01
Pump 1: yes
Pump 2: no
Waterhammer
temporization: +28 “
Meter: yes
Planned flow:
015.50 m3/h
COMMUNIC. PARAM.
“check specific manual”
FILTER PARAMETERS
N. of filters: 3
Initial wait: 000”
Time of activation
by filter: 045 “
Pause between filters:04“
Units between cleanings
Volume: 01850 m3
Time: 2100 ‘
General of filters: no
Relation with P1: yes
Relation with P2: no
Max. number of
continuous cleanings: 3
Stop of sectors: no
GENERAL PARAMETERS
Pump 1 : yes
Temp. start: 018 “
Temp. stop: 012 “
Stopping the sectors: no
Pump 2 : yes
Temp. start: 005 “
Temp. stop: 022 “
Stopping the sectors: yes
Assign inputs:
IM FM1 FM2 FM3 FM4
1 2 0 0 0
Assign inputs:
SC TM DM CS PS AL
4 2 0 5 0 0
Irrigation meter:
Value per pulse: 0100,00L
Delay without pulse: 010’
Fertilizer meter:
Value per pulse: 0001,00L
Delay without pulse: 010’
Detection delay
input SC: 030”
Detection delay
input TM: 180”
Assign outputs:
P1 P2
18 17
Assign outputs:
F1 F2 FG
15 14 16
Assign outputs:
M1 M2 LF
13 12 20
Assign outputs:
C1 C2 GC
10 9 11
PROGRAM PARAMETERS
Program: 12
Type of start: [schedule]
[sequential]
[input]
Units of irrigation:
[ hh:mm ]
[ m3 ]
Pre-irritation: 00:00
Post-irrigation: 00:00
VARIOUS PARAMETERS
Screen:
Automatic shut off: yes
Illumination: yes
Contrast: 5
Keyboard:
Sensitivity: 3
Sound level: 2
PIN security
PIN code: 0000
1
2
3
6
5
4
7
INSTALLER PARAM.
1. Erasure
2. Events
3. Access codes
4. Act. of options
5. Various
6. Communications
7. Language
8. Updating software
9. Backup param.
8
