SKF CMDT 391 - Sensor Controls and Indications

QuickCollect CMDT 391 / CMDT 391-Ex 2 - 3
User Manual – Revision B
Figure 2 - 4.
The SKF QuickCollect app for mobile devices.
Sensor Controls and Indications
Figure 2 - 5.
Sensor controls and LEDs.
Power button
Battery LED
Communication LED
All-purpose check LED
Power button – Powers the sensor on and off. When the sensor is off, pressing the
power button will immediately turn on the sensor.
