Ski-Doo REV Series User Manual

FAN-COOLED
MODEL
380F 550F
SUMMIT/EXP.
—
9
Drive sprocket
number of teeth
Others 10
Brake system Hydraulic caliper, self adjusting
EXPEDITION
—
406 mm (16 in)
Track nominal width
Others 381 mm (15 in)
GTX 3456 mm (136 in)
SUMMIT/EXP.
—
3456 mm (136 in)Track nominal length
Others 3074 mm (121 in)
EXPEDITION
—
31.8 mm (1.25 in)
X PACKAGE
—
25.4 mm (1 in)
SUMMIT
—
38.1 mm (1.5 in)
Track profile height
Others 18.4 mm (0.72 in) 22.3 mm (0.88 in)
Deflection
35-40 mm
(1-3/8 - 1-9/16 in)
30-35 mm
(1-3/16 - 1-3/8 in)
Track adjustment
Force
(1)
7.3 kg (16 lb)
Track alignment
Equal distance between edges of
track guides and slider shoes
Suspension
SUMMIT
—
R.A.S. (A-Arm)
Front suspension
Others R.A.S. (A-Arm)
R.A.S.
(A-Arm/sway bar)
Front suspension max. travel 229 mm (9 in)
GTX SC-136
SUMMIT/EXP.
—
SC-136Rear suspension
Others SC-4
GTX 330.7 mm (13 in)
SUMMIT/EXP.
—
330.7 mm (13 in)
Rear suspension
max. travel
Others 381 mm (15 in)
_________________________
157

Ski-Doo REV Series Specifications

General

Chassis	REV
Track Width	15 in
Fuel Capacity	10.6 gal
Seating Capacity	1
Reverse	Available on most models
Electric Start	Available on most models
