Ski-Doo REV Series User Manual

Remove metal particles from magnet.
Refill up to upper mark using recommended oil, refer to SPECIFICA-
TIONS.
CAUTION: Do not use other unrecommended types of oil when
servicing. Do not mix synthetic oil with other types of oil.
A32D02A
3
1
2
4
TYPICAL
1. Dipstick
2. Oil level
3. Level between marks
4. Magnet
Drive Chain Tension
Remove hair pin.
Fully tighten tensioner adjustment screw by hand, then back off only
far enough for hair pin to engage in locking hole.
184
_________________________

Ski-Doo REV Series Specifications

General

Chassis	REV
Track Width	15 in
Fuel Capacity	10.6 gal
Seating Capacity	1
Reverse	Available on most models
Electric Start	Available on most models
