Ski-Doo REV Series User Manual

Drive Belt Removal/Installation

WARNING
Remove tether cord cap before performing any maintenance
or adjustment, unless otherwise specified. Vehicle must be
parked in a safe place, away from the trail.
Removal
NOTE: Removal and installation of drive belt is easier when driven
pulley is held with brake so that it can not rotate. Apply parking brake,
for this purpose.
Remove tether cord cap. Open engine compartment and remove
belt guard.
Open the driven pulley with the drive belt installer/remover provided
in tool bag.
A03D2PA
DRIVE BELT INSTALLER/REMOVER
Screw drive belt installer/remover in the free threaded hole and tight-
en to open the pulley. Remove belt.
186
_________________________

Ski-Doo REV Series Specifications

General

Chassis	REV
Track Width	15 in
Fuel Capacity	10.6 gal
Seating Capacity	1
Reverse	Available on most models
Electric Start	Available on most models
