Ski-Doo REV Series User Manual

GSX/GTX/MX Z
MODEL
500 SS 600 HO
MX Z/GSX 25.4 mm (1 in) 25.4 mm (1 in)
Track profile height
GTX 22.3 mm (0.88 in)
—
Deflection 30-35 mm (1-3/16 - 1-3/8 in)
Track tension
Force
(1)
7.3 kg (16 lb)
Track alignment
Equal distance between edges of
track guides and slider shoes
Suspension
Front suspension R.A.S. (A-Arm/sway bar)
Front suspension max. travel 229 mm (9 in)
Rear suspension SC-4
MX Z/GSX 381 mm (15 in)
Rear suspension max.
travel
GTX 406.4 mm (16 in)
—
Electrical
Lightning system output 360 Watts @ 6000 RPM
Headlamp bulb HI/LOW beam 2 x 60/55 Watts (H-4)
Type NGK BR9ECS
(2)
Spark plug
Gap 0.45±0.05mm(.018±.002in)
Dimensions
MX Z/GSX 2885 mm (113.6 in)
Vehicle overall length
GTX
3075 mm (121.1
in)
—
Vehicle overall width 1217 mm (47.9 in)
MX Z 1105 mm (43.5 in)
GSX 1160 mm (45.7 in)
—
Vehicle overall height
GTX 1230 mm (48.4 in)
—
_________________________
161

Ski-Doo REV Series Specifications

General

Chassis	REV
Track Width	15 in
Fuel Capacity	10.6 gal
Seating Capacity	1
Reverse	Available on most models
Electric Start	Available on most models
