Ski-Doo REV Series User Manual

GSX/GTX/MX Z/SUMMIT
MODEL
600 HO SDI 800 HO
SUMMIT X
—
9 (159 in)
10 (144/151 in)
Drive sprocket
number of teeth
Others
10
Brake system Hydraulic caliper, self adjusting
MX
Z/GSX/GTX
381 mm (15 in)
Track nominal width
REN./REN. X/
SUMMIT
406 mm (16 in)
MX
Z/GSX/GTX
3074 mm (121 in)
REN./REN. X/
GTX
3456 mm (136 in)
SUMMIT 3648 mm (144 in) 3840 mm (151 in)
Track nominal length
SUMMIT X
(800 HO)
3648 mm (144 in)
3840 mm (151 in)
4038 mm (159 in)
MX Z/GSX 25.4 mm (1 in)
GTX 22.3 mm (0.88 in)
REN/RENX 31.8 mm (1.25 in)
SUMMIT 50.8 mm (2 in)
Track profile height
SUMMIT X
—
57.2 mm (2.25 in)
Deflection 30-35 mm (1-3/16 - 1-3/8 in)
Track tension
Force
(1)
7.3kg(16lb)
Track alignment
Equal distance between edges of
track guides and slider shoes
Suspension
Front suspension R.A.S. (A-Arm/sway bar)
Front suspension max. travel 229 mm (9 in)
164
_________________________

Ski-Doo REV Series Specifications

General

Chassis	REV
Track Width	15 in
Fuel Capacity	10.6 gal
Seating Capacity	1
Reverse	Available on most models
Electric Start	Available on most models
