Ski-Doo REV Series User Manual

A01F0BA
1
2
3
1
1. Guides
2. Slider shoes
3. Tighten on this side
Tighten lock nuts (some models only) and retaining screws.

WARNING
If lock nuts are not tightened properly, the adjusting screws
could loosen causing the track to become extremely loose and,
under some operating conditions, allow the idler wheels to
climb over the track lugs forcing the track against the tun-
nel causing the track to “lock”. Properly tighten wheel retain-
ing screws, otherwise wheel may come off and cause track to
“lock”.
198
_________________________

Ski-Doo REV Series Specifications

General

Chassis	REV
Track Width	15 in
Fuel Capacity	10.6 gal
Seating Capacity	1
Reverse	Available on most models
Electric Start	Available on most models
