Programming of internal call address
Next, each call station is given an internal call address. With this internal call address, it is possible to call the indoor
station from another indoor station. The call address which must be stored first is grayed out in the drawing.
Step
Description
6
Set the internal call address on the DIP-Switch. The second programmed call address is now the
internal call address.
7
Press the programming button for around 5 seconds until the two control tones sounds.
8
After this control tones sounds, there will be a third short tone. It signals that the call address has been
programmed. The number of short tones signals to which memory location the call address was saved.
9
Repeat the process until all indoor stations have been assigned their own internal call address.
In the next steps, the internal call numbers of the remaining indoor station are assigned to each indoor station.
It is possible to speak between indoor stations. The call address which must be stored first is grayed out in the next
drawing.
Step
Description
10
Set the corresponding internal call address on the DIP-switch of the respective internal indoor station.
11
Press and hold the programming button. The programming button is located on the back of the indoor
station.
12
Within 2 seconds, press the desired internal call key on the front of the indoor station.
This button is used to call the stored internal call address.
13
Press this key combination for around 5 seconds until the two control tones sounds.
14
Release both buttons. The internal call assignment is now done
15
Repeat the process until every indoor station has been assigned to each internal call address of the
remaining indoor stations.
