After successful programming of the internal call addresses into the indoor stations, it is possible to speak between
the indoor stations.
The internal call is sent picking up the receiver and pressing the internal call key on the front of the indoor station.
7 Resetting the BS2012
To reset the indoor station to the factory setting it is necessary to follow the steps below:
Step
Description
1
Pull off the a+/b- terminal on the back of the indoor station.
2
Press the programming button (Prog.) on the back of the indoor station and keep it pressed.
3
Plug in the a+/b- terminal again.
4
After a few seconds, an acknowledgment tone sounds, indicating that the operation was successful.
Once the indoor station has been reset to factory setting, all settings are deleted and have to be made again.
8 Technical data
Electric data
Voltage a+ / b-
19 – 23 VDC
General
Ambient Temperature
-10°C to +45°C
Humidity
20% to 90% not condensing
Housing
Plastichousing.
Dimensions (width x height x depth)
89 x 230 x 23 mm
Type
IP20
