Set the DIP switch to the internal receiving address (= 2nd position in your
storage space, in the example above B1), which responds to internal
calls sent to the indoor station.
4
Keep hold of the programming button at the back of the device for ve
seconds until you hear a signalling tone.
After this signal tone another two shorter tones are audible when the
second call address is programmed to indicate that this call address has
been saved in the second internal storage location.
5
B2
Set the internal call address (= internal call address of indoor station
2, saved on rst internal call key, in the example above B2) at the DIP
switch.
6
+
Keep hold of the programming button on the back of the device and also
keep hold of key 1 within two seconds. Hold both keys at the same time
for ve seconds until a signal tone is heard. Thus key 1 is assigned inter-
nal call address B2, i. e. if key 1 is pushed, indoor station 2 will be called.
7
B3
Set the DIP switch to the internal call address (= internal call address of
indoor station 3, saved on the internal call key 2, in the example above
B3), this will be called by pushing the respective bell button at the door
station.
8
+
Keep hold of the programming button at the back of the device and, with-
in two seconds, also keep hold of the key 2. Keep hold of both keys for
ve seconds until you hear a signal sound. Thus key 2 has is assigned
the internal call address B3, i. e. if key 2 is pushed, station 3 will be
called.
Attention
We recommend setting the DIP switch back to the main call address (= rst call ad-
dress programmed) after the programming is nished, so that it can easily be recog-
nized which bell button belongs to which indoor station in case of a breakdown..
After programming the rst indoor station go on programming indoor stations 2 and 3 in the same way.
8.5 Reset to default
+
At rst unplug terminals a+/b-.
Keep hold of the programming key while connecting the device to the BUS to reset all set-
tings to default and delete all programmed call addresses and internal call addresses at the
same time.
A signal tone indicates that the reset has been performed successfully.
