25
Support Hotline: +49 (0) 2661 98088-112
Support E-Mail: support@sks-kinkel.de
Version No. 3.0
Document No. 97005003
SKS-Kinkel Elektronik GmbH
Indoor station HT4600, Receiver, 2-wire
EN
1 Installation instructions
IMPORTANT!
READ CAREFULLY BEFORE USE!
KEEP FOR FUTURE REFERENCE!
2 Description
The HT4600 indoor station is able to communicate with SKS door stations and other SKS indoor stations, a door can be
unlocked and certain special functions can be controlled.
This manual applies to the following SKS items:
✓ HT4600 with 4 buttons (items 20000903, 200028)
✓ HT4600 with 10 buttons (item 200010)
2.1 Contractual use
3 Optical and acoustic signalling of door calls, oor calls and internal calls
3 Accept calls using the receiver
3 Open the door
3 Switch on light (only with an additional switching actor)
3 Use only indoors in places free from dripping or spraying water
2.2 Features
3 SKS BUS technology
3 Key functions: Opening door, adjusting volume of calls and ringtones, muting (ringtone is reactivated automat-
ically after 12 hours)
3 Switching functions possible (without additional wires, using switching actuator 300022 or BUS actuator mod-
ule 300095)
3 Optical call signalling with LEDs
3 Receiver is held by a magnet (allows for an optimal operability at any age)
3 Audio privacy function
3 One-man installation and programming
3 Parallel operation of up to 4 indoor stations optional
3 8 door call and 4 oor call ringtones
3 Ringtone volume can be adjusted in 5 steps
3 Optional 6 additional keys for internal call function
3 Surface-mounting
2.3 Scope of Delivery
3 Indoor station HT4600 incl. receiver
3 Receiver cable
3 Instruction manual
