Indoor station HT4600, Receiver, 2-wire
EN
4 Signalling
LED 1 & 2: Optical signalling of calls and
ringtone switched o󰀨/automatic door opener active
LED 2: Key operation recognized
5 Terminal designation
Terminal Designation
a+/b- BUS terminals
E+/E- Floor bell
L+/L- RMA to connect Radio bell 800765 or Basic additional
loudspeaker 300097
5.1 Connection
The HT4600 indoor station is connected via terminals a+/b- to
the 2-wire audio BUS.
Optionally a oor bell (normally open relay) may be connected
to terminals E+/E-.
