PART I : SETTING UP THE AZ-GTix MOUNT
7
1.5
Eyepiece assembly
1.Inserting eyepiece for refractor and Maksutov
(Fig.1.5.a).
2.Ioosen the thumbscrew on the end of the focus tube.
3.Insert the diagonal into the focus tube adn re-tighten the thumbscrew to hold the diagonal
in place
4.Loose the thunbscrews on the diagonal
5.Insert the desired eyepiece into diagonal and secure by re-tighening thumbscrews
Fig.1.5a
refractor
Maksutov
