Informationdisplayshowsletterg:

























TEXT: "g = 3"- Data Transmission-fault-Length. Transmitter identification sheet Pg ll
TEXT: "g = 6"- Data Transmission-fault-Length. Transmitter identification sheet Pg ll
With boom fully retracted, ensure the cables are wound evenly on each reeling drum starting with T1.
YES
Are Link wires fitted to correct
connections across WI, W2 or W3 (if
the
y
are re
q
uired
)

NO
Fit or Refit Link wires as per
Transmitter board description Pages
8/9
YES
24 volts on Data bus of Transmitter
b
oard Terminals 1 & 2
Fit or Refit Link wires as per
Transmitter board description Pages
8/9
Fit or Refit Link wires as per
Transmitter board description Pages
8/9
NO Voltage
LOW Voltage
YES
Are Voltages present on connections
4
,
5
,
6
,
7
,
8 or 9
NO
Fuse blown on transmitter board?
YES
Check transmitter terminal box for
water ingress or condensation.
Replace fuse.
Fuse remains intact?
NO
Replace Transmitter Board
YES
