This product uses the following terms to classify the potential hazards that may be caused by improper operation.
Note: If not follow the instructions, it may cause property damage and minor injuries.
Note: If not follow the instructions, it may cause property damage, major accidents and serious injuries.
Warning: Misuse of this product may result in injury, damage or loss of property. Read the manual carefully
before using this product. This item is not a toy. This item is intended for use by professional UAV operators and
installers only. Donot use this product if you lack the knowledge and expertise to install and maintain UAV radio
equipment. Do not use unapproved or unofficial components with this system. Operators must strictly follow
the operation guides set forth in this manual. Skydroid does not accept any liability for the use or misuse of this
product.
ATTENTION
A.Overview
1.Product Features
①The H16 series uses the newest surging processor, equipped with an Android embedded system and
advanced SDR technology, also with a super protocol stack to make the image clearer, lower latency, longer
distance transmission, and stronger anti-interference. Wildly applied for drones, Robots, industrial controlled
equipment, etc.
② Supports rich interfaces such as HDMI, RJ45, sensor interface, dual serial ports passthrough transmission,
SBUS, aerial photography, FPV security, fire protection, power, mapping robot, border control, etc.
③ IP67 design, based on waterproof, dust free and drop-resistant materials and structure to ensure its great
using feel and durability.
④ H16 uses 7-inch FHD high-brightness display, Original A grade screen,1800 nits brightness IPS LCD screen,
which can be viewed clearly under the sun. Supports 1080P high-definition digital image transmission. The
dual-antenna signals complement each other, with super-strong signals and ultra-long transmitting distances,
combined with algorithm control and out-of-step frequency hopping algorithms, greatly increasing the ability to
communicate with weak signals. So you don’t need to worry about the flight distance during flight operations,
just explore a wider scenery. H16’s video transmission distance is around 5-10km, H16 Pro’s video transmission
distance is around 20-30KM.
⑤ Integrated with high energy density lithium ion battery, 18w fast charging, can work for 8-15 hours after
2 hours of charging. The consistent survival thinking in the wilderness allows you to have no concerns about the
reliability of our equipment.
⑥ H16/H16 Pro supports rich interfaces such as HDMI, RJ45, sensor interface, dual serial port passthrough
transmission, SBUS, etc. And supports many brands cameras, pan-tilts, pods and other video equipment.
Provide development kit, SDK and technical support, support video suspension, support ground station of
mainstream flight control, support QGC and wireless RTSP video stream sharing.
⑦ The use of weather silica gel, frosted rubber, stainless steel, and aviation aluminum alloy makes the
extreme operating feel, and also meets the harsh conditions of outdoor use of drones. H16 is dust-free and
waterproof in the fuselage, control switches, and various peripheral interfaces. Protective measures such as
splashing can ensure stable and smooth operation of the equipment in harsh environments.
⑧ Rich ground-end interface, Coach PPM input + output, RJ45 network interface, long-distance connection
to the internal network, Type-C Android high speed USB interface, OTG interface can be connected to U disk and
network card, etc., expanded TF card slot.
⑨ An independent 2-dimensional gimbal joystick makes the gimbal flying with great facility, like a duck to
water.
2.Main purpose and scope of application
It is used to remotely operate helicopters, fixed wings, multi-rotors, vehicles, ships, etc. for video image
transmission (optional camera), data transmission, and control drone flight.
3.Specifications
PRODUCT DATA
Endurance
Update way
Model No.
Working voltage
Frequency
Size
Applications Helicopter,fixed wing,multi-rotor,unmanned vehicle,unmanned boat,etc.
6-20 Hrs
APP Update online
H16/H16 PRO
4.2V
2.400-2.483GHz
272*183*94mm
Charging port
Weight
Channels
RF Power
Frequency hopping
Battery
TYPE-C
1034g
16
20DB@CE/23DB@FCC
Newest FHSS
20000mA/H
Remote Controller Specification
3
