Index
No.
Skyjack
Part No.
Qty. Description
SKYJACK, Page 7SJIII Compact Series
143909
Section 3 - System Component Identification and SchematicsService and Maintenance
2H-13 103655 1 VALVE, Control (Lowering) (ANSI/CSA)
2H-13B 103655 1 VALVE, Control (Lowering) (CE)
2H-13A 134822 1 VALVE, Control (Deceleration) (Model 3215 ANSI/CSA)
2H-13C 134822 1 VALVE, Control (Deceleration) (Model 3215 CE)
2H-13-1 107629 1 VALVE, Control (Holding) (ANSI/CSA)
2H-13B-1 107629 1 VALVE, Control (Holding) (CE)
2H-25 128113 1 VALVE, Control (Cushion)
2H-59B 132749 1 VALVE, Control (Proportional)
3H-14 106273 1 VALVE, Control (Lift)
3H-17 103623 1 VALVE, Control (Brake)
4H-15 153334 1 VALVE, Control (Reverse drive) (Hytos) (includes 4H-16)
128317 1 VALVE, Control (Reverse drive) (Hytos) (includes 4H-16) (If equipped)
4H-16 - 1 VALVE, Control (Forward drive) (Hytos)
4H-23 153334 1 VALVE, Control (Right steer) (Hytos) (includes 4H-24)
128317 1 VALVE, Control (Right steer) (Hytos) (includes 4H-24) (If equipped)
4H-24 - 1 VALVE, Control (Left steer) (Hytos)
C2 130709 1 CYLINDER (Lift)
C3 121087 1 CYLINDER (Steer)
C4 127667 1 CYLINDER (Brake)
CB1 147888 1 VALVE, Counterbalance (2750 psi)
F1 109568 1 FILTER, Return
MI 139412 1 MOTOR, Hydraulic drive (White Hydraulics)
M2 139412 1 MOTOR, Hydraulic drive (White Hydraulics)
MB1 127629 1 BLOCK, Manifold (Main)
MB2 139307 1 BLOCK, Manifold (Drive)
MB3 128113 1 BLOCK, Manifold (Cushion valve)
MB4 130480 1 BLOCK, Manifold (Holding valve)
MB5 126761 1 BLOCK, Manifold (Lowering valve)
MB9 132748 1 BLOCK, Manifold (Proportional control)
MB10 136419 1 BLOCK, Manifold (Deceleration valve) (Model 3215)
O2 130046 1 ORIFICE (0.063” diameter) (Lowering) (Model 3219)
O3 108002 1 ORIFICE (0.040” diameter) (Cushion)
O4 130407 1 ORIFICE (0.051” diameter) (Brake)
O5 108002 2 ORIFICE (0.04” diameter) (Steering)
O6 105281 1 ORIFICE (0.067” diameter) (Emergency Lowering)
O7 147656 1 ORIFICE (0.024” diameter) (Drive)
P1 147661 1 PUMP, Hydraulic
PT1 134431 1 TRANSDUCER, Pressure (2000 psi) (Model 3215)
134432 1 TRANSDUCER, Pressure (3000 psi) (Model 3219)
R1 104534 1 VALVE, Relief (System)
R2 104534 1 VALVE, Relief (Lift)
V1 107271 1 VALVE (Emergency lowering)
V2 103136 1 VALVE (Free-wheeling)
3.5 Hydraulic Schematic Parts List AC
