Skyjack SJ 3215 - Main Manifold Harness and Holding Valve Harness (ANSI;CSA)

SKYJACK, Page 19SJIII Compact Series
143909
A B C D E F G H
V
Z
Y
X
W
3.13 Main Manifold Harness and Holding Valve Harness (ANSI/CSA)
M147331AB_S3
02 - WHITE
13 - BLACK
TO MAIN MANIFOLD HARNESS
PIN 2 - WHITE
PIN 1 - BLACK
TO HOLDING VALVE
13
02
HOLDING VALVE
SJ3E 3219
13 - ORANGE (18 AWG)
02 - WHITE (18 AWG)
13
02
13
02
LOWERING VALVE
13 - ORANGE
02 - WHITE
FORWARD VALVE
BLACK HEIRSHMAN
PIN 1 - 16 WHITE/BLACK
PIN 2 - 02 WHITE
REVERSE VALVE
GREY HEIRSHMAN
PIN 1 - 15 BLUE
PIN 2 - 02 WHITE
INSERT ORIENTATION
BOTTOM VIEW
RIGHT STEER VALVE
BLACK HEIRSHMAN
PIN 1 - 23 BLACK/WHITE
PIN 2 - 02 WHITE
LEFT STEER VALVE
GREY HEIRSHMAN
PIN 1 - 24 BLUE/BLACK
PIN 2 - 02 WHITE
15
TO ELECTRIC PANEL - 12 WIRES
00 - WHITE (14 AWG)
02 - WHITE
13 - ORANGE
13A- ORANGE (3215 ONLY)
14 - BLACK
15 - BLUE
16 - WHITE/BLACK
17 - BLUE/RED
23 - BLACK/WHITE
24 - BLUE/BLACK
25 - ORANGE/GREEN
59 - ORANGE/BLACK
PROPORTIONAL VALVE
59 - ORANGE/BLACK
02 - WHITE
BRAKE VALVE
17 - BLUE/RED
02 - WHITE
02
17
59
02
HOLDING VALVE
13 - ORANGE (18 AWG)
02 - WHITE (18 AWG)
02
SPLICE #1
02
SPLICE #2
LIFT VALVE
14 - BLACK
02 - WHITE
02
SOFT STOP VALVE
13A - ORANGE
02 - WHITE
02
14A
02
CUSHION VALVE
25 - ORANGE/GREEN
02 - WHITE
02 25
16
13
GREY
GREY
BLACK
02
BLACK
LOWERING VALVE
13 - ORANGE
02 - WHITE
13
13A
02
02
FORWARD
23
02
RIGHT
MOTOR (-)
00 - WHITE
(14 AWG)
00
LEFT
24 02
REVERSE
SJ3E 3215
AB
