SECTION 1, Page 11SJ 600, 800 & 1000 Series
122883AH
May 2002
Figure 1-1. SKYJACK SJ-800 Series Work Platform
OPERATOR’S
CONTROL BOX
ENTRY
GATE
MAIN
PLATFORM
LIFTING
MECHANISM
HYDRAULIC TANK
AND FUEL TANK
SIDE CABINET
ENGINE
TRAY
HYDRAULIC/
ELECTRIC
SIDE
CABINET
Work Platform Major Component Identification
