Skyjack SJ-600 Series User Manual

SECTION 1, Page 9SJ 600, 800 & 1000 Series
122883AH
May 2002
Table 1-1 Specifications And Features
Family 600 Series 800 Series 1000 Series
Model 7027 7127 7135 8831 8841 9250/9250A
Weight*
8,600 lbs.
(3450kg)
7,920 lbs.
(3593kg)
9,550 lbs.
(4332kg)
9,757 lbs.
(4426kg)
11,410 lbs.
†
(5176kg)
14,200 lbs.
(6441kg)
Width
70”
(1.78 m)
71.5”
(1.82m)
87”
(2.21m)
92”
(2.34m)
Length
119”
(3.02 m)
150”
††
(3.81m)
137.5”
(3.5m)
176”
(4.47m)
Platform
Size
65” x 112.5”
(1.65 x 86m)
64” x 117”
(1.63 x 2.97m)
68” x 133.5”
(1.73 x 3.39m)
74” x 168”
(1.88 x 4.27m)
Working
33’
(10.1m)
41’
(12.5m)
37’
(11.28m)
47’
(14.3m)
56’
(17.1m)
Platform
Elevated
27’
(8.23m)
35’
(10.7m)
31’
(9.45m)
41’
(12.5m)
50’
(15.2m)
Platform
Lowered
60”
(1.52m)
60.5”
(1.54m)
68”
(1.73m)
59”
(1.50m)
69”
(1.75m)
123”
(3.12m)
Height
Drive
Full Full**
26’***
(7.92m)
Tires
Please Refer to Table 2-2. for tire specification and usage.
Normal
Drive
3.0 mph
(4.8km/h)
3.5 mph
(5.6km/h)
2.0 mph
(3.2km/h)
Elevated
Low Drive
.6 mph
(0.97km/h)
.35 mph
(0.56km/h)
.6 mph
(0.97km/h)
Raise
(Rated Load)
39 sec. 40 sec. 40 sec. 80 sec. 90 sec. 67 sec.
Speed
Lower
(Rated Load)
33 sec. 40 sec. 40 sec. 53 sec. 44 sec. 72 sec.
Ford
Gasoline
Not Applicable 1300 (Low) / 2800 (High)
Kubota
Diesel
1300 (Low)
2800 (High)
1600 (Low) 2800 (High) 1300 (Low) / 2800 (High)
Engine (RPM)
Kubota
Gasoline
1500 (Low)
3900 (High)
2050 (Low) 3600 (High) Not Applicable
Gradability
35% 30% 25%
* Weights are approximate, refer to serial nameplate for specific weight. Values shown are for standard 2WD
machines with a manual extension platform (SJ 600) and no extension platforms (SJ 800 and SJ1000).
** ANSI Only, CE drivable until 26.0’ (7.92 m)
*** Model 9250 Only, model 9250A is drivable at full height (50’(15.2m))
† Weight is approximate. Refer to serial nameplate for CSA or CE models.
†† Tires mark fore/aft extremity of machine.
CE Kubota Diesel Models
Sound Pressure & Power Levels
NET INSTALLED POWER: 17.1kW
S
OUND PRESSURE @ OPERATOR STATION: 79 dB
G
UARANTEED SOUND POWER LEVEL: 103 dB

Skyjack SJ-600 Series Specifications

General

Brand	Skyjack
Model	SJ-600 Series
Category	Lifting Systems
Language	English
