Page 48 December 2007
SJRT Compact Series
Engine Powered
Start Operation Section 3 - Operation
3.8-5 To Drive Forward or Backward
WARNING
Be aware of blind spots when operating
the aerial platform.
WARNING
Ensure that there are no personnel
or obstructions in the path of travel,
including blind spots.
1. Activate platform control console (refer to
Section 3.8-3).
2. On platform control console, select lift/torque/drive
switch or lift/drive switch to “
” drive position.
3. Activate and hold “ ” enable trigger switch.
4. Move controller handle “ ” forward or
“
” backward to desired speed and direction
of platform travel.
5. Return controller to neutral center position to stop.
Release “ ” enable trigger switch.
WARNING
To protect against unintended movement
of the aerial platform, push in the
emergency stop button after you have
arrived at your desired location or
elevation.
3.8-6 To Steer
1. Activate platform control console (refer to
Section 3.8-3).
2. On the platform control console, turn
lift/torque/drive switch or lift/drive switch to
“
” drive position.
3. Activate and hold “ ” enable trigger switch.
4. Press “ ” rocker on top of controller handle in
either direction to steer.
NOTE
Steering is not proportional. Driving and
steering may be active at the same time.
