Skyjack SJ 9250 - Page 82

Page 86 Mid Size & Full Size RTs
Engine Powered
Labels Section 5
No. Label Pictorial Description
10
Glow Plug
Select to activate glow plugs.
11
Horn
Select to sound horn.
12
Low/High Torque
Select “ ” low speed (high torque) or “ ” high speed (low
torque).
13
Controller Connector Pinout
Controller connector pinout.
Platform Control Console (Continued)
13
11
10
12
