Mid Size & Full Size RTs
Engine Powered
Page 85
Section 5 Labels
9 8 7
5
6
No. Label Pictorial Description
5
Raise/Off/Lower Platform
Select “ ” to raise the platform, “ ” to turn power off or “ ”
to lower the platform.
6
Lift/Off/Drive
Select “ ” to enable lift, “ ” off or “ ” drive mode.
7
Emergency Stop
Push to disable controls
8
Lift Enable
Select to enable lift mode.
9
Start Engine
Select to start engine.
Platform Control Console (Continued)
