Skyjack SJ16 Operating Manual

Section 4 Tables
Table 4.3 Specifications and Features
MODEL SJ12 SJ16
Weight
*
863 kg 980 kg
Overall Width
77.5 cm 77.5 cm
Overall Length
140 cm 140 cm
Platform Size (Inside)
68.6 x 85.0 cm 68.5 x 85.0 cm
Platform Traversing
40.64 cm 40.64 cm
Working Height
5.66 m 6.75 m
Platform Elevated Height
3.6 m 4.75 m
Stowed Height
178.6 cm 178.6 cm
Drive Height
Full Full
Lowered Platform Height
45.72 cm 45.72 cm
Lift Time (Rated Load)
13 - 16 s 16 - 25 s
Lower Time (Rated Load)
13 - 17 s 17 - 19 s
Normal Drive Speed
3.1 - 4.0 km/h 3.1 - 4.0 km/h
Elevated Drive Speed
0.6 - 0.8 km/h 0.6 - 0.8 km/h
Gradeability (Ramp Angle
[Reverse/Forward])**
30% / 25% 30% / 25%
Tires (Solid Rubber)
309 x 100 mm 309 x 100 mm
Type
ATF Dexron III ATF Dexron III
Tank Capacity
4.92 L 4.92 L
280AB_CE
* Weights are approximate; refer to serial nameplate for specific weight.
** Refer to Section 3.9 Loading/Unloading for more details.
Vibration - acceleration to which operator's body is subjected
does not exceed 0.5 m/sec2.
Height
Standard Operating Times
Chassis
Hydraulic Oil
Emission sound pressure level at platform does not exceed 70 dB(A).
Vertical Mast
Page 51
TM

Skyjack SJ16 Specifications

General

Gradeability	25%
Drive Motor	24V DC
Max Gradeability	25%
Platform Height	16 ft
Lift Capacity	500 lbs
Machine Width	0.76 m
Overall Width	0.76 m
Drive Speed (Stowed)	4.8 km/h
Drive Speed (Raised)	0.8 km/h
Turning Radius (Inside)	0 in
Power Source	24V DC Electric
