2.17 Dimension Diagrams - SJ40 T+
75°
C
B
A
D
2.69 m
[8 ft 9.75 in]
10.34 m
[33ft 11 in]
14.19 m
[46 ft 6.5 in]
12.36 m
[40 ft 6.5 in]
5.93 m
[19 ft 5.25 in]
7.73 m
[25 ft 4.25 in]
2.40m
[7 ft 10.5 in]
2.44 m
[8 ft ]
A 0.35 m
[13.75 in]
B 1.11 m
[43 in]
C 1.34 m
[52.75 in]
D 0.27 m
[10.75 in]
E
D
D 0.27 m
E 0.04 m
A
B C
2.44 m/1.83 m
[96 in/72 in]
170°
A 0.91 m
[36 in]
1.62 m
[64 in]
C 1.12m
[3 ft 8 in]
B 2.29 m
[7 ft 6 in]
2.24 m
[7 ft 6 in]
360°
5.18 m
[17 ft ]
