Rough Terrain Scissors
December 2007 Page 27
Section 2 - Familiarization Function Tests
It is the responsibility of the operator to read, completely understand and follow all instructions and warnings
contained in this operating manual and on the aerial platform.
FAMILIARIZATIONFAMILIARIZATION
• Test Free-wheeling
1. Ensure path of intended motion is clear.
2. Release the brake manually (refer to
Section 2.5-2).
3. Turn free-wheeling valve knob
counterclockwise to a fully opened
position and attempt to push/pull the
MEWP.
Result: MEWP should move.
4. Turn free-wheeling valve knob clockwise
to a fully closed position for normal
operation.
5. Reengage the brake (refer to
Section 2.5-2).
Brake Hand
Pump
Freewheel
Valve
Brake Auto
Reset Valve
Emergency
Lowering Valve
Main Power Disconnect
Switch
Emergency Stop
Button
Platform/Engine/Base
Key Switch
Base Control Console
Main Manifold
To Next Page
