Page 52 December 2007
Rough Terrain Scissors
Start Operation Section 3 - Operation
3.8-6 To Steer
1. Activate platform control console (refer to
Section 3.8-3).
2. Select off/lift/drive key switch to “ ” drive
position.
3. Activate and hold “ ” enable trigger switch.
4. Press “ ” rocker on top of controller handle in
either direction to steer.
NOTE
Steering is not proportional. Driving and
steering can be activated at the same
time.
3.8-7 To Select Drive Torque
1. High Torque: Select high torque when ascending
or descending grades, traveling on rough terrain
or when loading or unloading aerial platform. To
activate high torque, select low/high speed range
switch to “
” low speed (high torque) position.
WARNING
Aerial platform must be in fully retracted
position when operated on any grade.
Driving while elevated on any grade may
result in death or serious injury.
2. Low Torque: Select low torque when traveling on
a flat level surface. To activate low torque, select
low/high speed range switch to “
” high speed
(low torque) position.
WARNING
To protect against unintended movement of
the aerial platform, push in the emergency
stop button after you have arrived at your
desired location or elevation.
