Skytech: 5310P
REV. 1-20-14 Page 4
Before installation, make sure you turn the slide switch to • OFF. After installation, make sure you turn the slide switch
to REMOTE.
The remote receiver can be placed on the replace hearth or under the replace behind the control access panel. •
Use the wires attached to the remote receiver to connect to the gas valve or the electric module (piggyback connec-•
tors have both male & female terminals for exibility).
Be sure that the connectors do not touch each other or other bare metal surfaces; this will cause the appliance to turn •
ON. The connectors may be wrapped with electrical tape to prevent this.
INSTALLATION
Protection from extreme heat is very important. The remote receiver should be kept away from temperatures exceeding
130ºF. Extreme heat can cause damage, which is not covered under warranty.
WARNING
This remote control system must be installed exactly as outlined in these instructions. Read all instructions completely
before attempting installation. Follow instructions carefully during installation. Any modications of this remote control
or any of its components will void the warranty and may pose a re hazard.
Consult gas appliance manufacturer’s instructions and wiring schematics for proper placement of all wires. All electronic
modules are to be wired to manufacturer’s specications.
The following wiring diagrams are for illustration purpose only. Follow instructions from manufacturer of gas valve and/
or electronic module for correct wiring procedures. Improper installation of electric components can cause damage to
electronic module, gas valve and remote receiver.
WIRING INSTRUCTIONS
A qualied electrician should install the remote control system.
1 2 3 4 5 6
REMOTE RECEIVER
TERMINAL BLOCK
ON MILLIVOLT
GAS VALVES
TH
TP
TP
TH
THERMOPILE/
PILOT LIGHT
To 110VAC
input
MILLIVOLT VALVES
MILLIVOLT SYSTEM CHECK
Ensure that the pilot ame is lit.•
Slide the 3-position button on the remote receiver to the • ON position. The main gas ame (i.e., the re) should ignite.
Slide the button to • OFF. The main ame should extinguish (the pilot ame will remain on).
Slide the button to • REMOTE, then press the ON button on the transmitter to change the system to ON. The main gas
ame should ignite.
Connect one wire from the remote receiver to the TH terminal •
on the gas valve.
Connect the other wire from the remote receiver to the TH/TP •
terminal on the gas valve.
Fig. 10
